Reach RX

Reach RX2

Lightweight, all-band RTK GNSS receiver with tilt compensation, designed specifically for use with NTRIP corrections and supplied with a mobile app for convenient field operation.

Functionality & Capabilities

• Full multi-band GNSS support: GPS, GLONASS, Galileo, BeiDou, QZSS, NavIC;
• RTK positioning accuracy: 7 mm + 1 ppm;
• Tilt compensation accuracy: 2 mm + 0.3 mm/°;
• Optimized for operation with NTRIP correction services;
• Mobile app control for iOS and Android;
• Up to 16 hours of continuous work;
• Li-ion battery with USB Type-C charging.

Advantages

• Multi-band GNSS tracking;
• Tilt compensation for faster field measurements;
• Compact and lightweight (280 g);
• Long battery life — up to 16 hours;
• MFi-certified: works with ArcGIS Field Maps, Survey123 and QField;
• Intuitive mobile workflow with no external controllers.

GNSS Specifications

• GPS: L1C/A, L2C, L5;
• GLONASS: L1OF, L2OF;
• Galileo: E1-B/C, E5a, E6;
• BeiDou: B1I, B1C, B2a, B3I;
• QZSS: L1C/A, L1C/B11, L2C, L5;
• NavIC: L1-SPS, L5-SPS.

Package Includes

• Reach RX2;
• USB Type-C cable.
